M-A352AD10
- Бренд： EPSON
- Размер/Корпус： 48 x 24 x 16 mm
- Параметр： 15G
- Ось обнаружения： x, y, z
- Интерфейс： SPI, UART
- Напряжение питания： 3.3V
- Рабочая температура： -30°C~+85℃
- Параметры продукта
- Бренд： EPSON
- Размер/Корпус： 48 x 24 x 16 mm
- Параметр： 15G
- Ось обнаружения： x, y, z
- Интерфейс： SPI, UART
- Напряжение питания： 3.3V
- Рабочая температура： -30°C~+85℃
Features
The M-A352 is a three axis digital output accelerometer featuring ultra-low noise, high stability, and low power consumption using fine processing technology of Quarts. Incorporating both high accuracy and durability, the versatile M-A352 is well suited to a wide-range of challenging applications such as SHM, seismic observation, condition monitoring for industrial equipment, and pose detection for industrial machinery (i.e. construction machinery/attachments, agricultural machinery/ implements, robots).
| Product Name | M-A352AD |
|---|---|
| Size | 48 x 24 x 16 mm |
| Weight | 25 grams |
| Noise Density | 0.2 uG/√Hz,rms |
| Output Range | ±15 G |
| Resolution | 0.06 µG/LSB |
| Bandwidth | 460 Hz (Max.) |
| Data Output Rate | 1000 Sps (Max.) |
| Shock Survivability | 1,000 G |
| Digital Serial Interface | SPI/UART |
| Operating Temperature Range | -30 to +85 °C |
| Power Consumption | 13.2 mA (typ.) @3.3V |
| Output Mode Selection (each axis) | Acceleration, Tilt Angle |
Applications
1. Construction and civil engineering customers
- Vibration-based structural health monitoring
(e.g., monitoring the vibration characteristics of structures and judging their health & integrity) - Measurement of low-frequency environmental vibration, etc.
2. Large machines and large structures
- Monitoring the safety of large structures
(e.g., pipelines and large plants)
3. Seismic sensing
- Measurement of vibrations accompanying earthquakes
