Item		Symbol	Specifications				Conditions/Remarks
Supply voltage		V_CC	1.80 V Typ.		2.50 V Typ.	3.30 V Typ.
Supply voltage		V_CC	1.62 to 1.98V	1.98 to 2.20V	2.20 to 2.80V	2.70 to 3.63 V
Output frequency range		f₀	0.67 MHz to 170 MHz
Storage temperature		T_stg	-40℃ to +125℃				Storage as single product
Operating temperature		T_use	G: -40℃ to +85℃ H: -40℃ to +105℃
Frequency tolerance *1		f_tol	±50 x 10^-6				Average frequency of 1s gate time
Current consumption		I_CC	3.4mA Max.	3.5mA Max.	3.6mA Max.	3.7mA Max.	T_use= +105℃		No load f₀= 20 MHz
			2.9mA Typ.		3.0mA Typ.	3.2mA Typ.	T_use= +25℃		No load f₀= 20 MHz
			5.7mA Max.	6.0mA Max.	6.9mA Max.	8.3mA Max.	T_use= +105℃		No load f₀= 170 MHz
			4.9mA Typ.		5.9mA Typ.	7.0mA Typ.	T_use= +25℃		No load f₀= 170 MHz
Output disable current		I_dis	3.4mA Max.	3.4mA Max.	3.5mA Max.	3.7mA Max.	OE=GND , f₀ = 170 MHz
Standby current		I_std	0.9μA Max.	1.0μA Max.	1.5μA Max.	2.5μA Max.	T_use= +105℃		ST = GND
Standby current		I_std	0.3μA Typ.	0.4μA Typ.	0.5μA Typ.	1.1μA Typ.	T_use= +25℃		ST = GND
Symmetry		SYM	45% to 55%				50% V_CC Level
Output voltage (DC characteristics)		V_OH	90% V_CC Min.				[mA]
							tr / tf	Vcc	A	B	C	D
							Default (f₀>40MHz) Fast	I_OH	-2.5	-3.5	-4.0	-5.0
							Default (f₀>40MHz) Fast	I_OL	2.5	3.5	4.0	5.0
							Default (f₀≦40MHz)	I_OH	-1.5	-2.0	-2.5	-3.0
		V_OL	10% V_CC Max.				Default (f₀≦40MHz)	I_OL	1.5	2.0	2.5	3.0
							Slow	I_OH	-1.0	-1.5	-2.0	-2.5
							Slow	I_OL	1.0	1.5	2.0	2.5
							A: 1.62 to 1.98 V , B: 1.98 to 2.20 V C: 2.20 to 2.80 V , D: 2.70 to 3.63 V
Output load condition		L_CMOS	15pF Max.
Input voltage		V_IH	70% V_CC Min.				OE or ST
Input voltage		V_IL	30% V_CC Max.				OE or ST
Rise and Fall time	Default	tr / tf	3.0 ns Max.				f₀> 40MHz		20% V_CC to 80% V_CC L_CMOS=15pF
	Default		6.0 ns Max.				f₀ ≦ 40MHz
	Fast		3.0 ns Max.				f₀=0.67to170MHz
	Slow		10.0 ns Max.				f₀=0.67to20MHz
Disable Time		t_stp	1 μs Max.				Measured from the time OE or ST pin crosses 30 % Vcc
Enable Time		t_sta	1 μs Max.				Measured from the time OE pin crosses 70 % Vcc
Resume Time		t_res	3 ms Max.				Measured from the time ST pin crosses 70 % Vcc
Start-up time		t_str	3 ms Max.				Measured from the time Vcc reaches its rated minimum value, 1.62 V

*1 Frequency tolerance includes initial frequency tolerance, temperature variation, supply voltage variation, reflow drift, load drift and aging (+25 ºC, 1 year)

Product name

Pin description

Pin	Name	I/O type	Function
1	OE	Input	Output enable	High: Specified frequency output from OUT pin Low: Out pin is low (weak pull down), only output driver is disabled.
1	ST	Input	Standby	High: Specified frequency output from OUT pin Low: Out pin is low (weak pull down) Device goes to standby mode. Supply current reduces to the least as I_std.
2	GND	Power	Ground
3	OUT	Output	Clock output
4	Vcc	Power	Power supply

External dimensions

(Unit: mm)

To maintain stable operation, provide a 0.1uF by-pass capacitor at a location as near as possible to the power source terminal of the crystal product
(between Vcc - GND).

Footprint

(Unit: mm)
