YSX2012SK
- Brand： YXC
- Size/Package： 2.0 x 1.2 x 0.6 mm
- Parameter： 32.768KHz
- Load Cap： 7,9,12.5pF
- Freq Tolerance： ±10,±20ppm
- Operating Temp： -40℃~+85℃
- Package： 2P 2012
- Applications： mobile phone,Notebook and DSC
- Parameters
- Brand： YXC
- Size/Package： 2.0 x 1.2 x 0.6 mm
- Parameter： 32.768KHz
- Load Cap： 7,9,12.5pF
- Freq Tolerance： ±10,±20ppm
- Operating Temp： -40℃~+85℃
- Package： 2P 2012
- Applications： mobile phone,Notebook and DSC
Specifications
| Item / Type | YSX2012SK |
|---|---|
| Standard Frequency | 32.768KHz |
| Load Capacitance (CL) | 12.5pF, or specify |
| Frequency Tolerance(at 25 ℃) | ± 20 ppm , or specify |
| Parabolic Coefficient (B) | ( - 0.03 ± 0.01 ) * 10-6 / ℃2 |
| Turnover Temperature (Ti) | 25 ℃ ± 5℃ |
| Operating Temperature | - 40 ~ + 85 ℃ |
| Shunt Capacitance (C0) | 1.3pF typical |
| Motional Capacitance (C1) | 7.0fF typical |
| Level of Drive | 0.1 μW |
| Frequency Aging (at 25 ℃) | ± 3 ppm / year Max. |
| Storage Temperature | -55 ~ +125℃ |
| Equivalent Series Resistance(ESR) | 90KΩ Max |
External dimensions
(Unit: mm)
