YSX306GA
- Brand： YXC
- Size/Package： 8.0 x 3.8 x 2.5 mm
- Parameter： 32.768KHz
- Load Cap： 7,9,12.5pF
- Freq Tolerance： ±10,±20ppm
- Operating Temp： -40℃~+85℃
- Package： 4P 8038
- Applications： Small communication devices
- Parameters
- Brand： YXC
- Size/Package： 8.0 x 3.8 x 2.5 mm
- Parameter： 32.768KHz
- Load Cap： 7,9,12.5pF
- Freq Tolerance： ±10,±20ppm
- Operating Temp： -40℃~+85℃
- Package： 4P 8038
- Applications： Small communication devices
Specifications
| Item / Type | YSX306GA |
| Nominal Frequency Range | 32.768KHz |
| Vibration Mode | +2° X-cut Fundamental |
| Load Capacitance | 12.5pF, or specify |
| Frequency Tolerance (at 25 ℃) | ± 20 ppm , or specify |
| Operating Temperature | - 40 ~ + 85 ℃ |
| Storage Temperature | -55 ~ +125℃ |
| Shunt Capacitance | 2.0pF typical |
| Level of Drive | 1.0 μW Max. |
| Frequency Aging (at 25 ℃) | ± 5 ppm / year Max. |
| Turnover Temperature | 25 ℃ ± 5 ℃ |
| Temperature Coefficient | -0.036 ± 0.006ppm/℃2 |
| Motional Resistance | 50 KΩ Max. |
| Motional Capacitance | 3.0fF typical |
External dimensions
(Unit: mm)
