M-A352AD10
改進的抗衝擊能力，新標準加速度傳感器
- 品牌： EPSON
- 尺寸/封裝： 48 x 24 x 16 mm
- 參數： 15G
- 檢測軸： x, y, z
- 接口： SPI, UART
- 電壓： 3.3V
- 工作溫度： -30°C~+85℃
- 產品應用： 建築土木工程/大型機器大型結構/地震傳感測量
- Parameters
- 品牌： EPSON
- 尺寸/封裝： 48 x 24 x 16 mm
- 參數： 15G
- 檢測軸： x, y, z
- 接口： SPI, UART
- 電壓： 3.3V
- 工作溫度： -30°C~+85℃
- 產品應用： 建築土木工程/大型機器大型結構/地震傳感測量
Features
M-A352是一款採用Quarts精細處理科技的三軸數位輸出加速度計，具有超低雜訊、高穩定性和低功耗的特點。 多功能M-A352兼具高精度和耐用性，非常適合各種具有挑戰性的應用，如結構健康監測、地震觀測、工業設備狀態監測和工業機械（即建築機械/附件、農業機械/工具、機器人）的姿態檢測。
| Product Name | M-A352AD |
|---|---|
| Size | 48 x 24 x 16 mm |
| Weight | 25 grams |
| Noise Density | 0.2 uG/√Hz,rms |
| Output Range | ±15 G |
| Resolution | 0.06 µG/LSB |
| Bandwidth | 460 Hz (Max.) |
| Data Output Rate | 1000 Sps (Max.) |
| Shock Survivability | 1,000 G |
| Digital Serial Interface | SPI/UART |
| Operating Temperature Range | -30 to +85 °C |
| Power Consumption | 13.2 mA (typ.) @3.3V |
| Output Mode Selection (each axis) | Acceleration, Tilt Angle |
Applications
1. Construction and civil engineering customers
- Vibration-based structural health monitoring
(e.g., monitoring the vibration characteristics of structures and judging their health & integrity) - Measurement of low-frequency environmental vibration, etc.
2. Large machines and large structures
- Monitoring the safety of large structures
(e.g., pipelines and large plants)
3. Seismic sensing
- Measurement of vibrations accompanying earthquakes
