Item	Symbol	For RF Reference	Condition/Remarks
Nominal frequency range	f_nom	16.000MHz to 48.000MHz	Fundamental *1 Please contact us about available frequencies.
Storage temperature	T_stg	-40°C to +125°C	Store as bare product.
Operating temperature	T_use	-40°C to +85°C (+105 °C)	Please contact us about +85 °C < T_use
Level of drive	DL	200µW Max.	Recommended: 10µW
Frequency tolerance	f_tol	±10 × 10^-6	+25 °C Please contact us for requirements not listed in this specifications. *1
Frequency versus temperature characteristics	f_tem	±10 × 10^-6/-20°C to +75°C	Please contact us for requirements not listed in this specifications. *1
Load capacitance	CL	7pF to ∞	Please specify.
Motional resistance (ESR)	R1	As per below table	-40°C to +85°C, DL = 100µW
Frequency aging	f_age	±1 × 10^-6 / year Max. ^*1	+25°C, First year

External dimensions

(Unit: mm)

Footprint

(Unit: mm)
