AMWPH3015S

Product Introduction

Sunlord AMWPH3015S is the metric 3015 (3.0×3.0×1.5mm) automotive power inductor of the AEC-Q200 AMWPH series. Ferrite core, precision winding and magnetic-glue full shielding deliver high current density with low DCR in a slim profile, targeting LED lighting, BMS, smart cockpit and T-BOX low/mid-power rails from -55°C to +125°C.

Core Advantages

• Slim 1.5mm profile: 3015 metric size suits space-constrained T-BOX, V2X and gateway modules where height budget is tight.
• Wide 1–100μH coverage: one footprint spans decoupling, buck and boost filter values for flexible power-tree design.
• High current density: Isat up to 2.75A with DCR from 36mΩ in the 3015 class keeps efficiency high in mid-power rails.
• Magnetic-glue full shielding: low leakage flux reduces crosstalk with adjacent RF and sensor circuitry.
• AEC-Q200 qualified: halogen-free, RoHS compliant, automotive-grade reliability for production programs.

Key Specifications

Cross Reference & Replacement

Cross-reference alternatives: TDK (same-size AEC-Q200 shielded wire-wound, Japanese automotive standard), Murata (globally available automotive power inductors) and Fenghua Advanced (Chinese AEC-Q200 alternative with short lead time). AMWPH3015S matches their pads and core electricals.

Applications

FAQ

Q: Can AMWPH3015S replace TDK 3015-class power inductors?

A: Yes — metric 3015 footprint, compatible pads and matching Isat/DCR, with the same magnetic shielding and AEC-Q200 qualification.

Q: What is the SRF range of AMWPH3015S?

A: 6.8MHz to 107MHz depending on inductance value, sufficient for automotive switching frequencies.
