AS1A2012
High performance and high strength ferrite materials, high current and high reliability
- Brand： Sunlord
- Size/Package： 2.0×2.0×1.2mm
- Parameter： 1.0-4.7μH
- Rated Current： 0.75-1.65A
- Package： SMD
- Operating Temp： -55℃~+150℃
- Applications： ADAS/Infotainment system/LED Lighting/Airbag/Intemet of vehicle
- Parameters
- Brand： Sunlord
- Size/Package： 2.0×2.0×1.2mm
- Parameter： 1.0-4.7μH
- Rated Current： 0.75-1.65A
- Package： SMD
- Operating Temp： -55℃~+150℃
- Applications： ADAS/Infotainment system/LED Lighting/Airbag/Intemet of vehicle
Automotive Power Inductors | AS1A2012
Product Introduction
Sunlord AS1A2012 is the most compact member of the 2025-launched AS1A automotive power inductor family — heat-resistant, low-loss and AEC-Q200 qualified. The 2012 magnetic-shielded wire-wound structure suits LED ambient lighting, cockpit rails and T-BOX/V2X modules from -55°C to +150°C.
Core Advantages
- Ultra-compact 2012 package: 2.0×1.2×1.0mm saves board space in dense automotive modules.
- Heat-resistant to +150°C: the 2025 AS1A platform is built for high-temperature automotive environments.
- Low loss at light load: 73–310mΩ DCR and 1.2–2.4A Isat match low-power rails like ambient lighting and T-BOX.
- Magnetic shielding: closed magnetic circuit keeps noise away from adjacent RF and V2X circuits.
- AEC-Q200 qualified: halogen-free, RoHS compliant for global automotive programs.
Key Specifications
| Parameter | Value |
|---|---|
| Type | Power Circuits (Automotive) |
| Package Size | Metric 2012 |
| Operating Temperature | -55°C–+150°C |
| Environmental Compliance | Halogen-free, RoHS compliant |
| Inductance | 1μH–4.7μH |
| Tolerance | ±20% |
| DC Resistance (DCR) | 0.073 Ω–0.310 Ω (typ.) |
| Saturation Current (Isat) | 1.2A–2.4 A (typ.) |
| RMS Current (Irms) | 0.85A–1.83A (typ.) |
Cross Reference & Replacement
Cross-reference alternatives: Cyntec (same-size shielded wire-wound, global mainstream), ROHM (AEC-Q200 shielded power inductors) and Microgate (Chinese alternative with short lead time). AS1A2012 matches their pads and core characteristics.
Applications
LED ambient lighting, DRL power circuits
instrument cluster power, infotainment
T-BOX modules, V2X units, gateways
FAQ
Q: Is AS1A2012 a 2025-new platform?
A: Yes — Sunlord launched the heat-resistant, low-loss AS1A series in 2025 with AEC-Q200 qualification across all sizes.
Q: Which circuits is AS1A2012 optimized for?
A: Low-power automotive rails: ambient lighting, cluster power, T-BOX, V2X and gateway modules.
