YSX211SL
- Brand： YXC
- Size/Package： 2.0 x 1.6 x 0.5 mm
- Parameter： 16-54MHz
- Load Cap： 8,9,12pF
- Freq Tolerance： ±10ppm
- Operating Temp： -40℃~+85℃
- Package： 4P 2016
- Applications： Mobile phone, Bluetooth, W-LAN ISM band radio
- Parameters
- Brand： YXC
- Size/Package： 2.0 x 1.6 x 0.5 mm
- Parameter： 16-54MHz
- Load Cap： 8,9,12pF
- Freq Tolerance： ±10ppm
- Operating Temp： -40℃~+85℃
- Package： 4P 2016
- Applications： Mobile phone, Bluetooth, W-LAN ISM band radio
Specifications
| Item / Type | YSX211SL |
| Nominal Frequency Range | 16 ~ 54 MHz |
| Vibration Mode | AT Fundamental |
| Load Capacitance | 8pF, 9pF, 12pF, or specify |
| Frequency Tolerance （at 25 ℃） | ±10 ppm, ± 15 ppm, ± 20 ppm, or specify |
| Frequency Versus Temperature Characteristics | ± 20 ppm, or specify |
| Operating Temperature | - 20 ~ + 70 ℃, - 40 ~ + 85 ℃, or specify |
| Storage Temperature | -40 ~ +85 ℃, or specify |
| Shunt Capacitance | 3 pF Max. |
| Level of Drive | 10-200 μW Max（10μW typical） |
| Frequency Aging （at 25 ℃） | ± 3 ppm / year Max. |
External dimensions
(Unit: mm)
