Item	Symbol	Specifications		Condition/ Remarks
Item	Symbol	For RF Reference	For Clock	Condition/ Remarks
Nominal frequency range	f_nom	16.000MHz to 54.000MHz		Fundamental Please contact us for inquiries regarding the available frequencies.
Storage temperature range	T_stg	-40°C to +125°C		Store as bare product.
Operating temperature range	T_use	-40°C to +85°C (+105 °C)		Please contact us about +85 °C < T_use
Level of drive	DL	100µW Max.	200µW Max.	Recommended: 1 to 100µW
Frequency tolerance (standard)	f_tol	±10 × 10^-6 *1	±30 × 10^-6	+25°C, please contact us for requirements not listed in this specification.
Frequency versus temperature characteristics (standard)	f_tem	±10 × 10^-6 *1	±30 × 10^-6	-20°C to +75°C, For the out of standard specifications, please contact us for inquiries.
Load capacitance	CL	6pF to ∞		Please specify.
Motional resistance (ESR)	R1	As per below table		-20°C to +75°C
Frequency aging	f_age	±1 × 10^-6 / year Max.	±5 × 10^-6 / year Max.	+25°C, First year

External dimensions

(Unit: mm)

#2 and #4 are connected to the cover (Please connect to ground)

Footprint

(Unit: mm)
